Mining & Chemical Industry

Application:

Filtration of sea water for the needs of oil companies [5200m³/hour]

Treatment Process:

Filtration of water with on-line automatic electric self-cleaning filter AF-912 MEGA composed of four units of filter screens, filter body and screens from stainless steel, extremely high resistance to impacts of sea water

Results:

Water free of mechanical impurities, ready for further treatment

Application:

Filtration of ballast water [1500m³/hour]

Treatment Process:

2 x automatic electric self-cleaning filter AF-916XLP, design for 100% duty and stand by

Results:

Water without any mechanical impurities larger than 80μm

Application:

Filtration of cooling water in chemical factory [4000m³/hour]

Treatment Process:

Removing particles from the cooling water. On-line automatic hydraulic self-cleaning “MEGA” filter with four stainless steel filter screens

Results:

Process water without mechanical particles for cooling in the production of ethanol

Application:

Very clean water for the needs in the production of chlorine [80m³/hour]

Water Source:

River

Treatment Process:

Pre-filtration with automatic electric filter AF-906PR with SST screen 50μm, automatic proportioning of coagulant, coagulant mixing in static mixer and a low speed filtration with sand filters F-6042

Application:

Filtration of cooling water in the production of chemical compounds for the needs of the metallurgical industry [600m³/hour]

Treatment Process:

Process water filtration with automatic hydraulic filters AF-808PR and AF-810XLP

Application:

Filtration of cooling water in the production of PVC granulate [450m³/hour]

Water Source:

Well

Treatment Process:

Filtration of process water with three automatic hydraulic self-cleaning filters AF-806PR

Application:

Filtration of cooling water in the production of polyethylene granulate [300m³/hour]

Treatment Process:

Filtration of process water with automatic hydraulic self-cleaning screen filter AF-808LOPR

Application:

Filtration of cooling water in the production of nitrogen derivatives of hydrocarbons [300m³/hour]

Treatment Process:

Filtration of process water with two automatic hydraulic self-cleaning filters AF-808PR

Application:

Drill Platform - Seawater pre-filtration before reverse osmosis [2 x 400m³/hour]

Treatment Process:

Pre-filtration pumping water with SST automatic electric self-cleaning filters AF-912 with extra fine screen. System on skid, high sea water resistant

Results:

Continuous supply of water for final treatment

Application:

Pre-filtration of main water supply to the drill platform [300m³/hour]

Water Source:

Arab Gulf

Treatment Process:

Pre-filtration with automatic hydraulic filters AF-208SW

Housing made from 6MO stainless steel, internals titanium and marine bronze

Flushing valve: seawater resistant aluminum

Screen: weave wire screen from INCONEL, PVC support

Tubes and fittings - all stainless steel 316 L

PP 03 PLC controllers (safety redundancy) with “slave connection” - fitted in explosion-proof enclosure

Filter design and manufacture according to ASME stamped

Results:

Excellent pre-filtration system, long-term seawater resistant
